Asawa Insulation Pvt. Ltd. is always committed to provide its customers with superiors products ensuring best quality. We also supply customized products to suit the specific needs of our clients.
RANGE OF PRODUCTS
• Perforated Cable Trays
• Ladder Type Cable Trays
• Cable Tray Accessories
• Cable Tray Supports
MATERIAL OF CONSTRUCTION (1.6-2.5 MM)
• CRCA (IS 1079)
• M.S. (Mils Steel) Hot Rolled (IS 513)
• Pre-galvanized M.S. (Mild Steel)
• Hot Dip Galvanized (80 – 100 Microns)
• Aluminium
PERFORATED CABLE TRAYS
| DESCRIPTION | LIGHT DUTY | MEDIUM DUTY |
|---|---|---|
| Tray Width (mm) | 75, 100, 150, 300, 450, & 600 | 75, 100, 150, 300, 450, & 600 |
| Length (mm) | 2,500 | 2,500 |
| Thickness (mm) | 1.2/1.5/1.6 | 2.0/2.5 |
| Slot Size (mm) | 20 X 10 | 20 X 10 |
| Tray Height (mm) | 25/50 | 50/75 |
LADDER TYPE CABLE TRAYS
| DESCRIPTION | LIGHT DUTY / HEAVY DUTY |
|---|---|
| Tray Width (mm) | 150, 300, 450, 600, 750, 900 |
| Length (mm) | 2,500 |
| Slot Size (mm) | 20 X 10 |
| Tray Height (mm) | 150/120/90/75/50 |
